Primary Emulsifier Oil Based Mud Additive for Drilling
Product introduction
It servesas a primary emulsifier in oil-base mud systems.
UBDrill-214 is comprises of modified amidoamine, oxidized fatty acids and low-toxic organic solvent.
It is formulated to give good emulsification, improved thermalstability of the invert emulsion,
and enhanced high-temperature, high-pressure (HTHP) filtration control.
Throughcomprehensive tests in a number of oil-base mud formulations with various base oils,
mud densities, oil/water ratios and hot-rolling temperatures,
it proves that at working temperature up to 149℃ (300℉), UBDrill-214 can maintain high ES (electrical stability), low HTHP filtrate and desired rheological property
Technical Index
Appearance |
Dark mobile liquid |
Flash point |
> 65℃ (149℉) |
Pour Point |
< -10℃(14℉) |
Specific gravity |
0.92 ~ 0.98 |
Odor |
no or slight odor |
Solubility |
soluble in oil. Insoluble in water |
Application
Prepares UBDrill-214 high performance oil-based drilling fluid system.
Functions as primary emulsifier and provide filtration control.
Helps maintain HPHT filtrate in a water-free state.
Improves the thermal stability and contamination resistance of oil-based mud.
Advantages
·Temperatures stable up to 300 °F.
·Formulated to produce flatter gel strengths when compared against conventional emulsification packages.
·Effective and thermally stable across a broad temperature range.
Recommended Handling
All personnel handling this material must handle it as an industrial chemical, wearing protective equipment and observing the precautions as described in the Material Safety Data Sheet (MSDS).
Packaging and Storage
200L/Drum
Store in dry, well-ventilated area. Keep container closed. Keep away from heat, sparks and flames. Store away from incompatibles. Follow safe warehousing practices regarding palletizing, banding, shrink-wrapping and /or stacking
